Unveiling of Flyback Converter Detailed
In the realm of electronics, the flyback converter is an old acquaintance that still holds a significant place in today's power supply applications. Although it may not be as common as it once was, its unique properties make it a valuable asset in certain scenarios.
Flyback converters, historically, have been utilised primarily as isolated DC-DC power supplies, particularly in older electronics and CRT displays. They were instrumental in generating high voltage for CRT anodes and providing regulated low voltage supplies. The core principle of a flyback converter lies in energy storage and transfer through a coupled inductor or transformer. During the switch's ON period, energy is stored in the transformer's magnetic field. When the switch turns OFF, this energy is released to the output through the secondary winding and diode, providing electrical isolation and voltage conversion in one step.
The compactness and efficiency of flyback converters, especially in low-to-medium power applications, have made them popular choices. In historical CRT equipment, the flyback transformer was essential for generating the very high voltages (tens of kilovolts) required for accelerating electrons inside the CRT tube. The flyback circuit allowed compact, efficient generation of these voltages from standard low voltage supplies.
As technology progressed, other power conversion methods became more prevalent, and flyback converters began to fade from the limelight. Today, switching regulators on a chip are typically used instead. However, understanding the design of the flyback converter is still considered interesting, and educational resources like the video analysis by Sam Ben-Yaakov provide an insightful look into its operation.
In his recent video, Sam Ben-Yaakov discusses the flyback converter circuit, demonstrating its workings and providing an LTSpice simulation of the circuit. The video analysis does not delve into the use of a transformer to convert AC to a lower AC voltage before the flyback converter, as it may be unnecessary in some cases. Instead, it focuses on the circuit's operation, highlighting its ability to obtain a high-voltage DC voltage directly from the wall without the need for a transformer and regulator in some cases.
The flyback converter operates as an oscillator, with the duty cycle of the oscillator in the flyback converter varying depending on the difference between the output voltage and a zener diode reference. This oscillation allows for energy storage and release, enabling voltage step-up and isolation.
Modern improvements in flyback converter designs include the integration of hybrid control (analog-digital) and advanced MOSFETs, which improve precision, efficiency, and flexibility in new designs. For instance, recent circuit reference designs like ROHM’s REF67004 showcase these advancements.
In summary, flyback converters were favored in older equipment due to their compact size, simple design, cost-effectiveness, and galvanic isolation between input and output. Although they are not as commonly used nowadays, they remain relevant in certain power supply applications. For those interested in learning more about flyback converters, resources such as Sam Ben-Yaakov's video analysis are available.
