Reason for Utilizing Flexible Printed Circuit Boards in Satellite Operations
In the fast-evolving satellite technology industry, the use of flexible printed circuit boards (Flex PCBs) is gaining traction due to their numerous advantages in satellite applications. These boards offer reduced weight, increased reliability, versatility, compactness, and lightweight design, making them ideal for spacecraft.
One of the key materials used in space applications is Kapton, a flex polyimide material, appreciated for its lightweight and vibration resistance properties. The sustainability of orbital collisions is an essential factor to be considered while designing Flex PCBs for space applications, and Kapton's ability to withstand greater stress than rigid PCBs makes it a suitable choice.
The viability of Flex PCBs for satellite applications hinges on their ability to operate without fault for up to 10 years. To achieve this, specific design considerations are necessary.
Material Selection is crucial, with materials chosen to withstand extreme thermal cycling (from about -150°C up to +150°C), harsh radiation exposure, and vacuum conditions. Polyimide substrates and ceramic materials are preferred due to their thermal stability, low outgassing properties, and radiation resistance.
Efficient thermal management is vital for aerospace circuit design to increase reliability. This can be achieved by designing to handle dramatic temperature variations, incorporating thermal vias, symmetrical layouts, and materials with compatible coefficients of thermal expansion (CTE) to prevent mechanical stress and failure during thermal cycling.
Radiation hardening is another essential aspect, with materials and components rated for high radiation being selected to prevent degradation and maintain electrical performance over long missions.
Mechanical robustness is also a key factor, with Flex PCBs engineered to endure intense vibrations, shocks, and dynamic bending movements. Control of bend radius is essential to avoid damage, and high-performance adhesives suitable for vacuum and temperature extremes are used to maintain layer integrity.
Weight and Space Optimization are critical factors, with Flex PCBs replacing bulky wire harnesses and connectors, significantly reducing mass and volume—essential for launch cost and orbital dynamics. Their conformal properties enable 3D packaging into tight or curved spaces within the satellite.
Signal Integrity is another important consideration, with controlled impedance and minimised crosstalk in high-frequency signals being critical for satellite communication and navigation systems. This requires precise trace design and layout.
Outgassing Prevention is also necessary to prevent contamination in the vacuum of space, ensuring long-term mission reliability. To achieve this, materials with low outgassing are used.
The operating temperature of PCBs designed for space applications should be more than 120 °C.
The basic elements of a satellite communication system consist of a satellite, a receiver, and a transmitter. The communication between a transmitter on Earth and a satellite is referred to as uplink, while the communication between a satellite and a receiver on Earth is termed as downlink.
Satellites are classified into three types: Fixed Satellite Service (FSS), Mobile Satellite Service (MSS), and Broadcast Satellite Service (BSS). FSS uses fixed receiving stations and is commonly used for applications like cable TV and internet relay stations. MSS deals with mobile ground systems and mobile phones, and is also used for communication among ship vessels and fleet vehicles. BSS broadcasts TV and radio signals directly to users, such as the satellite dishes used for broadcasting TV channels to subscribers.
The competition in the satellite technology industry is expected to increase due to the rising footprint of smaller players in the global landscape. Standards such as AS9100, created by the International Aerospace Quality Group (IAQG) for reliable products in the aerospace industry, ensure the quality and reliability of products used in space applications. Military-grade PCBs and aerospace PCBs should be manufactured as per the standards MIL-PRF-50884, MIL-PRF-31032, and MIL-PRF-55110.
In summary, designing Flex PCBs for satellites demands meticulous selection of high-performance materials (polyimide, ceramics), judicious thermal and mechanical design to withstand extreme temperatures, radiation, vibration, and vacuum conditions, while optimising for minimal weight and volume with reliable signal integrity and long-term durability.
