Handcrafted Replica of Commodore 64, Instrumented in Turing's Style
A hobbyist named DrMattRegan has embarked on an ambitious project to build a Commodore 64 without relying on its original chipset, offering a challenge for retrocomputing enthusiasts seeking more than simple assembly. In lieu of the core 6502 microprocessor, DrMattRegan is emulating the CPU's functionality with EPROMs (Erasable Programmable Read-Only Memory) and SRAM (Synchronous Random Access Memory) chips, along with conventional logic gates.
As DrMattRegan explains, he stores the 6502 CPU instructions and their micro-operations as microcode in EPROMs. These EPROMs serve as a "rulebook," sequencing the internal steps of each instruction to effectively control the datapath and execution flow, allowing the emulated CPU to behave identically to its real-world counterpart.
The working memory elements, such as CPU registers, program counter, stack pointer, and other internal state bits, are held in SRAM chips acting as a "notebook." These SRAM chips store intermediate values manipulated during instruction execution.
The control logic is implemented as a Finite State Machine (FSM) constructed from TTL (Transistor-Transistor Logic) chips. This FSM orchestrates the microcode steps and data flow signals to and from the SRAM and other logic, recreating the fetch-decode-execute cycle of the CPU at a logic gate level.
Thus far, the emulated 6502 CPU has been built on a printed circuit board (PCB) and is capable of running the Apple II version of the iconic game Pac-Man as a benchmark. Enthusiasts eagerly anticipate more updates in this intriguing series.
For those interested in DrMattRegan's previous work, his VIC-less VIC-20 project may provide valuable insights. The development of this project was helped by a tip from [Clint].
[1]: Microcode implementation for emulating the 6502 CPU:- EPROMs store microcode for sequencing internal steps of each instruction.- Control flow and datapath are controlled by reading from EPROMs.- Emulates the behavior of a real 6502 in a fully discrete and transparent manner.
[2]: SRAM for data and address storage:- Holds CPU registers, program counter, stack pointer, and other internal state bits.- Stores intermediate values manipulated during instruction execution.
[3]: TTL Finite State Machine (FSM) for control logic:- Controls microcode steps and data flow signals.- Orchestrates fetch-decode-execute cycle at a logic gate level.
[4]: Authentic, scratch-built replica of the 6502's behavior:- Rebuilds the CPU at a lower abstraction level than the original chip.- Transparent and open for study or modification.
